Transparent OLED
Description
Key Features
- Resolution : 1,920 × 1,080 (FHD)
- Brightness : 200 / 600 nit (APL 100% / 25%, without Glass)
- Transparency : 43% (Set)
- Bezel Width : Even 12.2mm (T/R/L/B)
All Spec
PANEL
Screen Size
139.7 cm (55)
Panel Technology
OLED
Back Light Type
OLED
Aspect Ratio
16:9
Native Resolution
1920 x 1080 (FHD)
Refresh Rate
120 Hz
Brightness
200/600 nit (APL 100%/25%, Without Glass)
Contrast Ratio
200,000 : 1
Color Gamut
DCI 90%, BT709 110%
Viewing Angle (H x V)
178 x 178
Color Depth (Number of Colors)
10bit(R), 1.07Bilion colors
Response Time
0.1 ms (G to G), 8 ms (MPRT)
Surface Treatment (Haze)
Haze 3% (SET), Hard coating (1H)
Life time
30,000 Hrs (Typ.)
Operation Hours (Hours/Day)
18/7 (Moving Content Only)
Portait / Landscape
Yes / Yes
Transparency
43% (SET)
CONNECTIVITY
HDMI In
Yes (1)
HDMI In (HDCP Ver.)
HDCP 2.2/1.4
DP In
Yes (1), HDCP1.3
RS232C In
Yes (1)
RJ45(LAN) In
Yes (1)
IR In
Yes (1), External IR Receiver
USB In
USB2.0 Type A(2)
RS232C Out
Yes (1)
RJ45(LAN) Out
Yes (1)
IR Out
Sharing RS232C Out
Daisy Chain
Input HDMI, DP / Output DP
MECHANICAL SPECIFICATION
Bezel Color
Transparent
Bezel Width
T/R/L/B : Even 12.2 mm
Weight (Head)
14.1kg (Head), 2.6 kg (Signage Box)
Packed Weight
30.0 kg
Monitor Dimensions (W x H x D)
1237.6 x 717.9 x 86.5 mm (Head) 381.6 x 217.6 x 42.8 (Signage Box)
Carton Dimensions (W x H x D)
1368 x 245 x 957 mm
PROTECTION GLASS
Thickness
3.0 mm
Tempered / Chemical strengthening
Chemical strengthening
Anti-Reflective
Yes (Film)
Shatter-Proof
Yes
FEATURE – HARDWARE
Internal Memory (eMMC)
16 GB
Temperature Sensor
Yes
FEATURE – SOFTWARE
OS Ver. (webOS)
webOS 23
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail Over
Yes
RS232C Sync
Yes
Local Network Sync
Yes
Video Tag
Yes (4)
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
PM mode
Yes
Wake on LAN
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
Scan Inversion
Yes
ENVIRONMENT CONDITIONS
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
POWER
Power Supply
Built-In Power
Power Type
95 W
POWER CONSUMPTION
BTU (British Thermal Unit)
27.84BTU/Hr(Typ.), 51.29BTU/Hr(Max.)
DPM
0.5 W
Power off
0.5 W
Max.
175 W
Typ.
95 W
CERTIFICATION
Safety
CB / NRTL
EMC
FCC Class “A” / CE / KC
ERP / Energy Star
Yes / No
SOFTWARE COMPATIBILITY
SuperSign CMS
Yes
SuperSign Control+
Yes
SuperSign Cloud
Yes
Mobile CMS
Yes
Connected Care
Yes
LANGUAGE
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Polski, Türkçe, Arabic
ACCESSORY
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender, MCX/Harness Cables(3000 mmx4ea/3000 mmx2ea) for connection between panel and Signage Box), DP Cable(2 m), LAN Cable(1.5 m), RS232 Cable(4P-4P,1.5 m), LC Cable(VLC,3 m), Screw(M4xL22,12EA / M4 Nut 12EA / M3xL5.5,8EA / M3xL3.5, 20EA), Shield Cover Assy’, Rubber Damper 4EA, MCX cable Holder 4ea, Stand (2 pole)
SPECIAL FEATURE
Conformal Coating (Power Board)
Yes
